NSN 6685-00-782-5249 NIIN 007825249 — Self-indicating Bime Thermometer

Home » FSG Index » FSG 66 - Instruments And Laboratory Equipment » FSC 6685 - Temperature And Humidity Measuring And Controlling Instruments Pressure » NSN 6685-00-782-5249

NSN

Item Name

Assigned

DEMIL

Shelf Life

UOM

Using Services

NSN:

		6685-00-782-5249
6685007825249

Description:

THERMOMETER,SELF-INDICATING,BIME

NSN Assigned:

01-JAN-60

DEMIL:

Shelf Life:

N/A

UOM:

1 EA

Using Services:

Navy, Coast Guard, Marines, Army, Air Force

6685-00-782-5249 Images

(for reference only) NSN 6685-00-782-5249

Price Quote Get an up to date pricing and availability quote for this product. Order online or over the phone.

Quality Commitment

Serving our customers with quality and safety first.

AS9120 Certified
Audited supply chain
ITAR Registered
DDTC Registered
HAZMAT Certified
Customer service objectives
Every product 100% inspected

6685-00-782-5249 Specification Set by the OEM (see RNCC code 3)

Overall Length ABHP:

3.406in. ⁓3-13/32"

Stem Length ALZD:

2.000in.

Design Type APGF:

fluctuating

Dial Diameter ASSP:

3.000in.

Scale Type ATEQ:

dial

Scale Measurement Range CSYG:

+20.000/+240.000 deg fahrenheit

Material MATT:

steel corrosion resisting meter case

Style Designator STYL:

straight form, horizontal dial

End Item End items to which 6685-00-782-5249 is a component of

A6N CHILLED WATER A/C SYSTEMS
A7N MAIN FEED PUMPS
A8N AIR COMPRESSORS, HIGH PRESSURE
A9N SYSTEMS, JP-5 AVIATION FUELS
ACN ELEVATORS, AIRCRAFT
AEN BOILERS, 1200 PSI
AGN L.P. COMPRESSORS
AHN FIRE PUMPS
EXN LOS ANGELES CLASS SSN (688)
