5977-00-464-8496 Specification Set by the OEM (see RNCC code 3)
0.492in.
0.200in. ⁓13/64"
spectroscopic feature
solid
electrode disc
0.125 in dia hole in center
graphite
MIL-E-8971 mil spec single material response
round
End Item End items to which 5977-00-464-8496 is a component of
- 02F AIRCRAFT, PHANTOM F-4
- 04F AIRCRAFT, STRATOFORTRESS B-52
- 05F AIRCRAFT, STRATOLIFTER C/KC-135
- 06F AIRCRAFT, HERCULES C-130
- 10F AIRCRAFT, F-111 (FMS ONLY)
- 15F HELICOPTER, GREEN GIANT H-3
- BTF ENGINE, AIRCRAFT, F100-PW-100 (F-15A/B/C/D)
- DLF ENGINE, AIRCRAFT, F100 PW220 (F-15C/D/E)
- NEF F117A UNIQUE SUPPORT EQUIPMENT
- PAF U-2 AIRFRAME
Cross Reference Parts Part numbers that meet the specification outlined on this page and set by the OEM
Identification Item Identification Guide (IIG) and Item Name Code (INC)
Definition Definition of approved item name (AIN): "ELECTRODE"
An item of electrically conductive material which acts as a terminal through which an electric current enters or leaves a liquid or gas. The item does not provide filler material or act as a lighting media. Excludes electrode, welding; electrode, cutting, tubular and electrode, carbon, lighting.
