NSN 9150-00-231-6689

9150-00-231-6689

NIIN 00-231-6689 - Utility Lubricating Oil

NSN 9150-00-231-6689 Classification

A refined mineral oil, with or without additives, suitable for applications which do not require special lubricants. It is commonly used for household uses, machinery, or the like. It may have added preservative qualities. Excludes:lubricating oil (with other modifiers).

2350-01-577-0830 end item identification, additives and petroleum base basic ingredient, any acceptable fatty material type, any acceptable lubricant type, -70.0 fahrenheit maximum pour point

National Stock Number: 9150-00-231-6689
Federal Supply Group: 91 - Fuels, Lubricants, Oils, and Waxes
Federal Supply Classification: 9150 - Hydraulic, Lubricating and Oils and Greases: Cutting
National Item Identification Number: 00-231-6689
Item Name Code: 14824
Assigned Date: Tue, Jan 1, 1963
Schedule B Code: 2710193080
Requires Demilitarization: DEMIL/MLI

NSN 9150-00-231-6689 Specification

Set by the OEM (See RNCC code 3)

End Item Identification: 2350-01-577-0830
Basic Ingredient: additives and petroleum base
Fatty Material Type: any acceptable
Lubricant Type: any acceptable
Maximum Pour Point: -70.0 fahrenheit
Minimum Flash Point And Test Method: 275.0 fahrenheit cleveland open cup
Quantity Within Each Unit Package: 1.000 quarts
Service Characteristics: corrosion resistive and oxidation resistant
Viscosity At Rated Temp: 12.00 minimum 100 deg fahrenheit and 7000.00 maximum -40 deg fahrenheit and 60000.00 maximum -65 deg fahrenheit

Quality Commitment

Quality, Safety, and Compliance in Every Supply Requirement

Serving aerospace, military, MRO, and industrial customers with quality-first sourcing, inspected products, audited supply chain processes, and compliance-focused support.

AS9120 Certified

Audited Supply Chain

ITAR Registered

DDTC Registered

HAZMAT Certified

Customer Service Objectives

Every Product 100% Inspected

Every product is 100% inspected to support quality assurance, safety, documentation, and dependable delivery for critical aerospace, defense, MRO, and industrial sourcing requirements.

NSN 9150-00-231-6689 Material

Hazmat, Precious Metals, Criticality, Environment, and ESD

(PMIC) Precious Metals Indicator

Item does not contain precious metal.

What does the A code means?

Precious metals indicator code (pmic): this code is to identify items that have precious metals as part of their content. Precious metals are those metals generally considered to be uncommon and highly valuable which are relatively superior in certain properties such as resistance to corrosion and electrical conductivity. The precious metals recovery program for the federal government encompasses gold, silver, platinum, and the platinum family which consists of palladium, iridium, rhodium, osmium, and ruthenium. See volume 10, table 160 and quick info on-line.

(HMIC) Hazardous Metal Indicator

Indicates information is in the hazardous materials information resource system (hmirs).

What does the Y code means?

Hazardous materials indicator code: a code established in the dlis total item record (tir) to identify to users of the federal catalog system all known or suspected hazardous items as defined by safety/health, transaction and/or environmental regulations, to serve as a flag that a procuring activity must acquire a material safety data sheet when a hazardous item is procured, and to inform federal catalog system users when more detailed information on an item is available in the hazardous material information system. See volume 10, table 179 and quick info on-line.

Criticality Code

The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

What does the X code means?

Criticality code, federal item identification guide: a code which indicates when an item is technically critical, by reason of tolerance, fit, application, nuclear hardness properties or other characteristic which affects identification of the item. See volume 10, table 181 and quick info on-line.

Cross Reference Parts

Part numbers that meet the specification outlined on this page and set by the OEM

Part Number	CAGE	RNCC	RNVC	DAC	RNAAC	MSDS	SADC
0X18-1QUARTCAN	K0851	5	2	6	ZG	-	-
9150-027	D9455	5	9	9	ZG	-	-
9150-027-1QUARTCAN	D9455	5	9	9	ZG	-	-
9150002316689	A00AM	6	9	9	YP	-	-
9150PL0020521	9009H	6	9	9	WP	-	-
ARPOLUBE 32033	Z2A69	5	2	3	ZA	-	-
CASTROL BRAYCO 300	U5F65	5	1	4	ZK	-	-
