NSN 5805-01-641-7300 NIIN 016417300 — Telephone

NSN
Item Name
Assigned
DEMIL
Shelf Life
UOM
Using Services
NSN:
5805-01-641-7300
5805016417300
Description:
TELEPHONE
NSN Assigned:
30-JAN-15
DEMIL:
NO
Shelf Life:
N/A
UOM:
--
Using Services:
--

Price Quote Get an up to date pricing and availability quote for this product. Order online or over the phone.

Part Number:
Quantity Requested:
Your Email:
Full Name:
Contact Phone:
Company:

Quality Commitment

Serving our customers with quality and safety first.

  •   AS9120 Certified
  •   Audited supply chain
  •   ITAR Registered
  •   DDTC Registered
  •   HAZMAT Certified
  •   Customer service objectives
  •   Every product 100% inspected
AS9120 Certified by SAI Global

5805-01-641-7300 Specification Set by the OEM (see RNCC code 3)

Iii End Item Identification AGAV:

9408 dig phone

Iii Part Name Assigned By Controlling Agency CXCY:

digital telephone

Cross Reference Parts Part numbers that meet the specification outlined on this page and set by the OEM

Part Number
Cage
RNCC
RNVC
DAC
RNAAC
Status
MSDS
SADC
Part Number:
9408
Cage Code:
4NCQ6
RNCC:
3
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:

Identification Item Identification Guide (IIG) and Item Name Code (INC)

INC
FIIG
Concept No.
App. Key
Cond. Code
Status
INC:
00306
FIIG:
T187-D
Concept No.:
App. Key:
DG
Cond. Code:
1
Status:
A

Definition Definition of approved item name (AIN): "TELEPHONE"

An item specifically designed to convert sound into variations of an electric current and to reconvert similar variations into their original sound with sufficient accuracy for clear intelligibility. It consists of a telephone transmitter, telephone receiver, and a switch and is primarily used for voice communications. Includes pedestal type, cradle type and hang-up type telephones. Does not include separate handsets or head and chest sets.

Packaging & Dimensions Packaging instructions, special markings, and approx. weight/dims

Pack Size
Pack Weight
Item Weight
Item Dim.
Pack Size:
--
Paclk Weight:
0.0000lbs
Item Weight:
--
Item Dim:
--
Container
OPI
SPI No.
SPI Rev.
SPC Mkg.
LVL A
LVL B
LVL C
Container:
--
OPI:
O
SPI No.:
SPI Rev.:
SPC Mkg:
00
LVL_A:
E
LVL_B:
Q
LVL_C:
LVL A Code (LVL_A) E

Packing shall be accomplished to meet the performance test requirements of astm-d4169, distribution cycle 18, assurance level 1.

LVL B Code (LVL_B) Q

Packing shall be accomplished in accordance with table c.ii for the packing level specified. closure, sealing and reinforcement shall be in accordance with the appropriate shipping container specification.

Procedure Indicator Code (OPI) O

Options can be exercised as to specific method of preservation or dod approved packaging materials to be used. however, basic preservation method shall be retained, supplemental data shall be complied with, and unit package dimensions shall not be increased by more than one inch. equal or better protection shall be given the item and there shall be no increase in the package cost.

Special Markings Code (SPC_MKG) 00

No special marking.

  Packaging Codes

OPI: Optional Procedure Indicator Code. A one position alpha code that indicates the allowable deviations from the prescribed requirements.

SPI No.: Special packaging instructions number.

LVL A/B/C: Indicates the type of shipping container required for level A, B, or C maximum packing protection.

SPC Mkg: A two position code that identifies the special markings applied to the container, which is part of the total pack to protect the contained item during preservation, packing, storage, transit and removal from the pack.

5805-01-641-7300 Material Hazmat, Precious Metals, Criticality, Enviroment, and ESD

HMIC
PMIC
ESD
ENAC
ADPE
CRITL
HMIC:
N
PMIC:
A
ESD:
A
ESD:
A
ADPE:
0
CRITL:
X
Hazmat (HMIC) N

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

Precious Metals (PMIC) A

Item does not contain precious metal.

Electrostatic Discharge (ESD) A

No known electrostatic discharge (esd) or electromagnetic interference (emi) sensitivity.

ADPE 0

Represents items with no adp components

Criticality X

The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

  Identification Codes

HMIC: Hazardous Material Indicator Code. A one position code that identifies a hazardous item.

PMIC: Precious Metal Indicator Code. A one position code which identifies items that have precious metals as part of their content. precious metals are those metals generally considered to be uncommon, highly valuable, and relatively superior in certain properties such as resistance to corrosion and electrical conductivity.

ESD: Electrostatic Discharge. Indicates if an item is susceptible to electrostatic discharge or electromagnetic interference damage. electrostatic discharge damage occurs when an accumulation of static electricity generated by the relative motion or separation of materials is released to another item by direct contact. electromagnetic interference damage occurs when an item comes into proximity with an electrostatic or magnetic field.

ENAC: Enviromental Attribute Code. Identifies items with environmentally preferred characteristics.

CRITL: Criticality Indicator Code. Indicates an item is technically critical by tolerance, fit, application, nuclear hardness properties, or other characteristics.

Solicitation History DLA solicitations for NSN 5805-01-641-7300

Solicitation
Ends
Qty
AMSC
Buyer
PR
SMB
Solicitation:
SPE8EN18T0484
End Date:
11/27/2017
Qty:
30 Ea
AMSC:
D
Buyer Code:
PEPCE
PR:
0071730981
SMB:
0%
Solicitation:
SPE8EN17T3590
End Date:
10/12/2017
Qty:
1 Ea
AMSC:
D
Buyer Code:
PEPCE
PR:
0071050640
SMB:
0%
Solicitation:
SPE8EN17T1486
End Date:
03/13/2017
Qty:
1 Ea
AMSC:
D
Buyer Code:
PEPCE
PR:
0067801485
SMB:
0%
Solicitation:
SPE8EN16T2767
End Date:
07/05/2016
Qty:
150 Ea
AMSC:
D
Buyer Code:
PEPCE
PR:
0064298022
SMB:
100%
