NSN 5306-01-381-1375 NIIN 013811375 — Internal Wrenching Bolt

NSN
Item Name
Assigned
DEMIL
Shelf Life
UOM
Using Services
NSN:
5306-01-381-1375
5306013811375
Description:
BOLT,INTERNAL WRENCHING
NSN Assigned:
11-OCT-93
DEMIL:
NO
Shelf Life:
N/A
UOM:
1 EA
Using Services:
Navy

Price Quote Get an up to date pricing and availability quote for this product. Order online or over the phone.

Part Number:
Quantity Requested:
Your Email:
Full Name:
Contact Phone:
Company:

Quality Commitment

Serving our customers with quality and safety first.

  •   AS9120 Certified
  •   Audited supply chain
  •   ITAR Registered
  •   DDTC Registered
  •   HAZMAT Certified
  •   Customer service objectives
  •   Every product 100% inspected
AS9120 Certified by SAI Global

5306-01-381-1375 Specification Set by the OEM (see RNCC code 3)

Thread Class AAJD:

3a

Thread Direction AAJF:

RIGHT-Hand

Thread Length AASA:

1.048in. ⁓1-1/16"

Fastener Length AASB:

3.047in. and 3.077in. ⁓3-5/64"

Head Style AASK:

BEVEL-Conical

Head Diameter AASL:

1.220in. and 1.230in.

Head Height AASU:

0.750in. ⁓3/4"

Locking Feature AAUM:

pellet threads

Internal Drive Style ABQZ:

hexagon

Nominal Thread Diameter AHYM:

0.750in. ⁓3/4"

Width Across Flats ASDB:

0.5630in. and 0.5660in. ⁓37/64"

Thread Quantity Per Inch CMLP:

16

Special Features FEAT:

0.249/0.252 in.hole dia:drilled hole 0.090 in. deep to accomodate locking pellet. 0.500 in. center of hole from end of thds.

Material MATT:

plastic polychlorotrifluoroethylene locking feature

Material Document And Classification MDCL:

ams 5662 assn std single material response fastener

Surface Treatment SFTT:

cadmium fastener and chromate fastener

Surface Treatment Document And Classification STDC:

QQ-P-416, CL1, TY2 fed spec single treatment response fastener

Thread Series Designator THSD:

unf

Cross Reference Parts Part numbers that meet the specification outlined on this page and set by the OEM

Part Number
Cage
RNCC
RNVC
DAC
RNAAC
Status
MSDS
SADC
Part Number:
92798-12-27
Cage Code:
56878
RNCC:
3
RNVC:
2
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
82577
RNCC:
7
RNVC:
2
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
32067
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
58998
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
07450
RNCC:
5
RNVC:
2
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
10174714
Cage Code:
A486G
RNCC:
6
RNVC:
9
DAC:
9
RNAAC:
WF
Status:
A
MSDS:
SADC:
Part Number:
10174714
Cage Code:
A486G
RNCC:
6
RNVC:
9
DAC:
9
RNAAC:
WF
Status:
A
MSDS:
SADC:
Part Number:
FIT7359-7
Cage Code:
58998
RNCC:
3
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
98752
RNCC:
7
RNVC:
2
DAC:
D
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
32067
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
58998
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
92798-12-27
Cage Code:
56878
RNCC:
5
RNVC:
2
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
82577
RNCC:
5
RNVC:
9
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
07450
RNCC:
5
RNVC:
9
DAC:
A
RNAAC:
ZZ
Status:
F
MSDS:
SADC:
Part Number:
10174714
Cage Code:
A486G
RNCC:
6
RNVC:
9
DAC:
9
RNAAC:
WF
Status:
A
MSDS:
SADC:
Part Number:
FIT7359-7
Cage Code:
58998
RNCC:
3
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
98752
RNCC:
7
RNVC:
2
DAC:
D
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
32067
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
58998
RNCC:
5
RNVC:
2
DAC:
5
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
92798-12-27
Cage Code:
56878
RNCC:
5
RNVC:
2
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
82577
RNCC:
5
RNVC:
9
DAC:
A
RNAAC:
ZZ
Status:
A
MSDS:
SADC:
Part Number:
654798-7
Cage Code:
07450
RNCC:
5
RNVC:
9
DAC:
A
RNAAC:
ZZ
Status:
F
MSDS:
SADC:
Part Number:
10174714
Cage Code:
A486G
RNCC:
6
RNVC:
9
DAC:
9
RNAAC:
WF
Status:
A
MSDS:
SADC:

Identification Item Identification Guide (IIG) and Item Name Code (INC)

INC
FIIG
Concept No.
App. Key
Cond. Code
Status
INC:
06666
FIIG:
A003B0
Concept No.:
App. Key:
BM
Cond. Code:
1
Status:
A
HEAD STYLE BEVEL-CONICAL style nsn 5306-01-381-1375
INTERNAL DRIVE STYLE HEXAGON style nsn 5306-01-381-1375

Definition Definition of approved item name (AIN): "BOLT,INTERNAL WRENCHING"

An externally threaded fastener whose threaded portion is of one nominal diameter, no. 10 (0.190 in.) (5 mm) or larger. It is designed with an internal socket or internal multiple spline for use with an internal driver. The head is beveled (conical) or cylindrical in shape. Items with cylindrical shaped heads must have an externally relieved body. A locking feature may be incorporated in the design of the head or threads. See also screw, cap, socket head. Excludes setscrew; screw, shoulder; bolt, shoulder; screw, externally relieved body; bolt, externally relieved body; and screw, machine.
