1.837in. and 1.843in.
1.887in. and 1.993in.
0.171in. and 0.176in.
aluminum alloy 2024
ams 4037 assn std single material response
triangle, sharp corners
A comparatively flat rigid item, with or without a centrally located aperture, designed to hold an annular bearing or a sleeve bearing in a fitted inclosure. It must have drilled and/or tapped holes for mounting purposes. Excludes end bell, electrical rotating equipment.
